Mini 2 in 1 LED Controller, 2.4GHz, Single Colour and Dual White, 12-24V DC, 6A

One small controller, two kinds of strip

This mini controller runs either single colour LED strip or dual white (CCT) strip. Press the SET button to switch mode: the indicator shows red for single colour and green for dual white. In dual white mode you can change the colour temperature as well as the brightness.

Smooth dimming

Brightness goes from 0.1% to 100% in 4096 steps, so the light fades evenly with no jumps at the low end. Bright for cooking or getting ready, low for a quiet evening.

2.4GHz wireless control

The controller works on 2.4GHz with a control distance of up to 30m. One controller pairs with up to 12 remotes, so you can control the same lights from several rooms. Remotes are not included. Auto-forwarding passes the remote signal on to the next controller, which extends the range across a larger home.

App and voice control

Add a 2.4GHz gateway and you can control the lights with the Tuya Smart app on your phone, or by voice with Alexa or Google Home. That lets you switch lights off when you are out, or set them by voice when your hands are full.

Fitting

The controller takes 12-24V DC from your LED driver and outputs the same voltage to the strip, up to 6A in total, which is 144w at 24V. It measures just 78.4 x 22.3 x 11mm, so it hides easily behind a cabinet or in a ceiling void. Wires push into the terminals, with the input and output clearly marked. It is IP20, so fit it indoors in a dry place. It works from -10°C to +40°C.

Specifications

• Type: mini 2 in 1 LED controller (single colour or dual white)
• Frequency: 2.4GHz
• Control distance: up to 30m
• Remotes: pairs with up to 12 (not included)
• Input voltage: 12-24V DC
• Output voltage: 12-24V DC
• Max output current: 6A
• Max output power: 144w
• Dimming: 0.1% to 100%, 4096 levels
• Smart control: Tuya Smart app, Alexa and Google Home via a 2.4GHz gateway
• IP rating: IP20
• Size: 78.4 x 22.3 x 11mm
• Working temperature: -10°C to +40°C
