Twin T8 LED Batten Fitting, 6ft (1800mm), White, Single End Connection

A twin fitting for 6ft LED tubes

This batten takes two 6ft (1800mm) T8 LED tubes, so you can light a workshop, warehouse aisle, garage, stock room or office with LED tubes in a simple, slim fitting. It is the fitting only; check your tubes are 6ft T8 LED tubes before you order.

For LED tubes only

The lampholders are wired for single end connection LED tubes. Do not use the fitting with fluorescent tubes or other lamp types.

White and slim

The white finish blends into a white ceiling, and the narrow body, 61mm wide and 71mm high, keeps the fitting neat. The body is iron.

Where to fit it

The batten is rated IP20 and is not protected against splashes or jets of water, so use it indoors, away from water: offices, shops, stock rooms, corridors, kitchens away from the sink and dry garages. It runs on 220-240v mains and is not dimmable.

Fitting

Have a qualified electrician wire the fitting, so the tubes are connected correctly.

Specifications

• Type: twin T8 LED batten fitting
• Takes: 2 x 6ft (1800mm) T8 LED tubes
• Connection: single end, LED tubes only
• Length: 1801mm
• Width: 61mm
• Height: 71mm
• Body: iron
• Finish: white
• Input voltage: 220-240v
• Dimmable: no
• IP rating: IP20
