360° Recessed Microwave Motion Sensor, White, 1-8m Range, 1200W, IP20

A recessed sensor that sits flush

This microwave sensor fits into the ceiling and sits flush, so it looks neat in hallways, offices and living spaces. The white finish blends with a white ceiling. It switches the connected lights on when it detects movement and off again after a set time.

360° coverage

It watches a full circle around it, so it suits open-plan areas where blind spots aren't welcome. The detection radius can be set from 1m to 8m to suit a corridor, an office or a shared room. Mount it at a height of 1.5m to 3.5m.

Microwave detection

The sensor uses a 5.8GHz HF microwave signal rather than detecting body heat, so it picks up small movements and can sense through lightweight obstacles.

Set it to suit the room

The time delay runs from 10 seconds to 12 minutes, so you can choose how long the lights stay on after the last movement. The daylight sensor can be set from below 3 lux to 2000 lux, so the lights do not come on when there is already enough natural light.

Load and supply

It handles up to 300W of LED or energy-saving lighting, or 1200W of incandescent lighting, on a 220-240V AC supply, which suits homes and light commercial spaces. The housing is UV-resistant polycarbonate, rated IP20 for dry indoor use. Have a qualified electrician fit it.

Specifications

• Type: recessed microwave motion sensor with daylight sensor
• Detection angle: 360°
• Detection radius: 1m to 8m, adjustable
• Frequency: 5.8GHz HF
• Mounting height: 1.5m to 3.5m
• Time delay: 10 seconds to 12 minutes
• Lux setting: below 3 lux to 2000 lux
• Maximum load: 300W LED or energy-saving, 1200W incandescent
• Supply: 220-240V AC
• Body: white UV-resistant polycarbonate
• Mounting: recessed, ceiling
• IP rating: IP20
